Products Product Description

Unstacked Cornermatic C and F Corners

Gami-Cornermatic-C-and-F-CornersUnstacked corners, referred to as "GAMI" under the Ductmate name, used for knock in/manual insertion. 16 Gauge 250 per box. The only difference between the stacked and unstacked Cornermatic is that the unstacked has no stacking notches on the legs. For contractors pushing in by hand, the notch on a stacked corner is often viewed as dangerous. Item Codes
Galvanneal Item Codes

Stacked Cornermatic
C and F

Cornermatic-C-and-FStacked in trays in each box for insertion by Corner Machines.16 Gauge 250 per box.Item Codes

Strap Pak Cornermatic C and F

Strap-Pak-Cornermatic-C-and-FCornermatic Style Corner, introduced as a replacement to the Sleeved Cornermatic and specifically used with Lockformer's Cornermatic Plus machines that have conversion kits.

Corner packaging: 80/Strap-Pak, 400/Master Carton,16,000/Skid
Conversion Kit Part Numbers:
Cornermatic Plus – CPLUSSHIM
Cornermatic Dual Head – DHCONKIT
*conversion kits provided to contractor at no charg
Item Codes
Install Guide
Video Demo

Ductmate Auto C

Ductmate-Auto-CManual Insert TDC Corner, 16 Gauge 250 per box.Item Codes

Ductmate Standard F

Ductmate-Standard-FOriginal Manual Insert TDF Corner, 16 Gauge 250 per box..Item Codes

Ward C and F

Ward-C-and-FManual Insert Ward Style, 14 Gauge Corner. 250 per box.Item Codes

Ductmate Versa Cleat

Ductmate-Versa-Cleat6" long, ideal for TDC Flange, but also clips onto TDF - 250 per box.Item Codes
Galvanneal Item Codes

Quad Cleat Plus

Quad Cleat PlusDuro Dyne's 6" 22 Gauge Quad Cleat Plus, the closest Cleat to the popular E55; works on TDF, TDC and TDX Flange. The Heavy Duty Quad Cleat Plus is designed specifically for high pressure, heavy duty transverse duct.Item Codes

Nuts/Bolts

Nuts-and-Bolts3/8" Nut and Bolt in 500 count box; also available in 100 count boxes.Item Codes
TDC/TDF Tools
Products Product Description

Corner Tool

Corner-ToolsThe Dyn-O-Mate Crimper installs the TDC or TDF corner and crimps the edge over to hold the corner in place.Item Codes

TDC Cleat
Tool

TDC-CleatWhen two pieces of Duct with TDC Flanges and a Gasket are butted together. The cleats are slid into the tools then snapped on to the flanges giving even pressure on the gasket and flange preventing leaks along the sides.
Item Codes

Versa Cleat
Tool

Versa-Cleat-ToolWhen two pieces of Duct with TDC Flanges and a Gasket are butted together. The cleats are slid into the tools then snapped on to the flanges giving even pressure on the gasket and flange preventing leaks along the sides.Item Codes

Cleater for Quad Cleat Plus

Cleater-for-Quad-Cleat-PlusCleat Tool for Quad Cleat Plus it is not required, but certainly will make it easier, specifically designed for Duro Dyne's Quad Cleat Plus.

This tool not only installs the Cleats, but also serves to easily remove it, no easy task since the Quad Cleat holds quite tight; magnet holds cleat in place but also handy storage.
Spec Sheet
Item Codes
