Products   Product Description

24 Gauge

24-Gauge-Pittsburgh-Machine Ideal for small to medium sized Sheet Metal contractors or job site manufacturing. Shown with optional Flanging Attachment and Floor Stand. Spec Sheet
Item Codes
Demo Video

20 Gauge

20-Gauge-Pittsburgh-Machine Ideal for small to medium sized Sheet Metal contractors or for fitting departments of large manufactures. This machine features hardened feed gauges and 3 piece shaft/roll/gear design. This machine comes with an outboard side that accommodates one of the three types of rolls: Double Seam (pipe lock), Drive Cleat, or Right Angle Flange (for male Pittsburgh). Spec Sheet
Item Codes
Demo Video

20 Gauge
High Speed

20-Gauge-Pittsburgh-High-Speed This 6-station machine forms a 5/16" Pittsburgh running at 100 feet per minute for increased production. Built on the same frame as Flagler's 16 Gauge machine, makes this the most robust 20 Gauge Roll Former on the market. Double matched "V" belts are driven by a 3-hp motor on standard 3-phase power. This machine has an outboard side with empty auxiliary shafts onto which one can install the Right Angle Flange Rolls (forms up to a 3/8" 90-degree flange depending on feed gauge adjustment). Although 70% of the sales of this 20 Gauge High Speed Pittsburgh machine are made with Right Angle Flange Rolls on the outboard side, Double Seam or Drive Cleat Rolls are other options for the outboard side. Spec Sheet
Item Codes

18 Gauge

18-Gauge-Pittsburgh-Machine This 7-station Machine forms a 3/8" Pittsburgh on 18-22 Gauge material running at 45-ft per minute. Arc welded heavy duty Steel frame with heavy top plate. Double matched "V" belts are driven by a 2-hp motor on standard 3-phase power. 3-piece shaft design virtually eliminates the high maintenance costs associated with other brands single shaft type. Machine is two sided; the other outboard side is available for optional rolls including Drive Cleat, Double Seam or 3-in-1 Rolls. Spec Sheet
Item Codes

16 Gauge

16-Gauge-Pittsburgh-Machine This 7-station Machine forms a 1/2" Pittsburgh on 16-20 Gauge material running at 45-ft per minute. Arc welded heavy duty Steel frame with top plate. Double matched "V" belts are driven by a 3-hp motor on standard 3-phase power. 3-piece shaft design virtually eliminates the high maintenance costs associated with other brands single shaft type. Machine is two sided; the other outboard side is available for optional rolls including Drive Cleat, Double Seam or 3-in-1 Rolls. Spec Sheet
Item Codes
