18/6 Plenum Wire Solid x 250-ft/Spool
Item CodeTSWP186SOLIDSKU555060423
Brand Southwire® Application For Class 2 power limited circuit cable, communications used in plenum thermostat control applications Conductor Type Bare Solid Copper Country of Origin US Jacket Color Beige Length 250 ft Number of Conductors 6 Packaging Type Reel Standard/Approvals C(ETL)us CMP/CL2P|Type CMP/FT6|NEC Article 725 and 800|UL 13 and 444 Type Type CL2P Plenum Warranty 1 year Limited Lifetime Alternate Part Number 17964519 Conductor Size 18 AWG Country USA Insulation Material PVC Jacket Material PVC Manufacturer Southwire® Outside Diameter 0.191 in Resistance 6.32 Ohm Temperature Rating -20 to 75 deg F Voltage 300 V AC
- Some installations require that thermostat wire be installed adjacent to the HVAC ducts. This creates a challenging environment for electrical wiring. Baroplen™ wires are constructed with high performance insulation and jackets rated for use in these harsh environments.
- Smooth jacket eliminates snagging and tearing
- PVC jacket, polypropylene insulation ensures excellent strip ability
- 42.7 lbs/1m ft nominal approximate cable weight
- 48 pF/ft nominal capacitance between conductors at 1 kHz
- 6.32 Ohm/1000 ft nominal DC resistance per conductor at 20 deg C
- Black, red, white, green, brown, blue insulation colors
- This cable consists of two bare copper insulated conductors with an overall jacket
$118.57
/ EAOut of Stock
Request a quote for more detailed pricing including freight and taxes.
